The METTLER TOLEDO VRS241 rail scales are designed for static rail car weighing of massive loads. Choose between two deck options, concrete or steel, and achieve safe, accurate, and reliable railcar weighments.
Robust Construction
Heavy-duty I-beams support massive loads applied by rail traffic.
Accuracy and Reliability
POWERCELL® PDX® load cells eliminate the junction box and
provide superior diagnostics.
Static Weighing
Available for both single or multi-draft railcar weighing.
Engineered-to-Order
Custom solutions are available for special projects in every industry.
Pseudo Single-Draft Weighing
Capture the weight of an entire railcar in one operation, providing lower handling costs, faster weighing, and higher accuracy.
Deck Options
Choose between steel and concrete for efficient installation with easy access to the load cell network.
Lightning Protection
StrikeShield™ lightning protection prevents costly downtime by applying multiple levels of protection.
Professional Expertise
Benefit from operational quality and audit-readiness from day one.
Description
VRS241 Rail Scale Technical Specifications
| Load Cell | 50 t SS POWERCELL PDX |
| Design | Modular I-beam design |
| Capacity | 340,000 lb (154,221 kg) for 4 load cells to 750,000 lb (340,194 kg) for 6 or more load cells |
| Profile | 29.75 in (75.6 cm) + rail |
| Scale Lengths | 12 ft – 6 in (3.8 m) to 75 ft (22.9 m) |
| Foundation Type | Pit or above ground |
| eMin | 50 lb (22.7 kg) |
| CC | 90-001A2 |
